Part
Number |
Chip
Materia |
Emitting Color |
Forward Voltage VF:(V) |
Dominant Wavelength
 D:(nm) |
Luminous Intensity
IV:(mcd)
|
Angle |
Test condition : IF=20mA |
MIN |
MAX |
MIN |
MAX |
MIN |
MAX |
|
Z054SWCLN |
InGaN |
White |
2.8 |
3.6 |
_ |
_ |
200 |
3500 |
35-120 |
Z054SBCLN |
InGaN |
Blue |
2.8 |
3.6 |
455 |
485 |
100 |
1000 |
Z054SGCLN |
InGaN |
Green |
2.8 |
3.6 |
500 |
540 |
100 |
5000 |
Z054SYCLN |
AIGaInP |
Yellow |
1.8 |
2.3 |
570 |
595 |
100 |
1500 |
Z054AYCLN |
AIGaInP |
Amber |
1.8 |
2.3 |
600 |
615 |
100 |
700 |
Z054SRCLN |
AIGaInP |
Red |
1.8 |
2.3 |
620 |
645 |
100 |
1000 |
